| Hardware | |
| RoHS 2.0 / REACH Compliant | |
| Operating Temperature | -20°C ~ 60°C |
| Dimensions | 38(L) * 38(W) * 40 (H) mm |
| Weight | TBD |
| Lens | ||
| Lens Composition | 5 Glass +2 Plastic + IR Filter | |
| Field of View | Mechanical (M) | 180° ±5% |
| Diagonal (D) | 175° ±5% | |
| Horizontal (H) | 157° ±5% | |
| Vertical (V) | 95° ±5% | |
| IR Wavelength (T50%) | 650 nm ±10nm | |
| Effective Focal Length (EFL) | 3.24 ±5% | |
| TV Distortion | ≦ 25% | |
| F/No | 2.7 ±5% | |
| Focus Mode | Auto Focus (AF) | |
| Focus Range | 10cm ~ 100cm | |
| Frames rate | 4K/ 30 fps 12MP/ 18 fps |
|
