| Hardware Issue | |
| RoHS 2.0 / REACH Compliant | |
| Operating Temperature | -20°C ~ 70°C |
| Dimensions | 38(L) * 38(W) * 30.31 (H) mm |
| Weight | TBD |
| Lens | ||
| Lens Composition | 4Glass + 5 Plastic + IR Filter | |
| Field of View | Mechanical (M) | 95° ±5% |
| Diagonal (D) | 88.2° ±5% | |
| Horizontal (H) | 80° ±5% | |
| Vertical (V) | 51° ±5% | |
| IR Wavelength (T50%) | 650 nm ±10nm | |
| Effective Focal Length (EFL) | 3.24 ±5% | |
| TV Distortion | ≦ 0.2% | |
| F/No | 2.7 ±5% | |
| Focus Mode | Fixed Focus (FF) | |
| Focus Range | 50cm ~ 150cm | |
